Reflow Cub Tshuab
Lub tshuab luam ntawv: siv cov hlau mesh kom xau solder paste rau hauv PCB padDocking chaw nres tsheb: thauj PCB pawg thawj coj saib, nrog rau kev tsis ua haujlwmMounter: mount cov khoom rau ntawm txoj hauj lwm ntawm PCBReflow soldering: yaj lub solder paste ntawm qhov kub thiab txias los ua cov khoom thiab PCB lo ua ke
Muaj nuj nqi
Reflow qhov cub tshuab
SMT ntau lawm kab
Lub tshuab luam ntawv -- Chaw nres tsheb docking -- Mounter -- Reflow soldering
Lub tshuab luam ntawv: siv cov hlau mesh kom xau solder paste rau hauv PCB ncoo
Docking chaw nres tsheb: thauj PCB pawg thawj coj saib, nrog rau kev ua haujlwm tsis zoo
Mounter: mount cov khoom ntawm qhov chaw ntawm PCB
Reflow soldering: yaj lub solder paste ntawm qhov kub thiab txias los ua cov khoom thiab PCB lo ua ke
Yuav ua li cas xaiv reflow soldering
Lub reflow soldering rau cov khoom sib txawv kuj txawv. Ntawm no peb siv lub teeb muag muag ua piv txwv. Nws yuav tsum tau muab sau tseg tias qhov reflow kub yuav tsum tau tswj kom zoo. Yog hais tias lub solder muab tshuaj yog tsawg heev rau yaj, txias soldering yuav tshwm sim; Siab dhau lawm, PFC yooj yim rau npuas. Tsis tas li ntawd, qhov kub ntawm preheating yuav tsum tsim nyog. Lub flux volatilizes tsis tiav thaum nws tsawg dhau, thiab muaj qhov seem tom qab reflow, uas cuam tshuam rau qhov tsos; Siab dhau lawm yuav ua rau ntxov ntxov volatilization ntawm flux, ua rau faulty soldering thaum lub sij hawm reflow, thiab tej zaum tin hlaws dai.
Reflow soldering parameters
Khoom qauv | ET-R8S |
TSIS MUAJ. ntawm thaj chaw cua sov | Sab saum toj 8 cua kub cua sov, qis 8 cua kub cua sov |
Ntev ntawm cua sov cheeb tsam | 3000MM |
cua sov txoj kev | Tag nrho cov cua kub ncig |
TSIS MUAJ. ntawm qhov chaw txias | 2 |
PCB siab tshaj plaws | 350MM IB |
Kev thauj mus los | sab laug (right-left) |
Conveyor siv qhov siab | 880 ± 20mm |
Txoj kev xa khoom | Mesh siv tsav ntxiv rau Chain (yeem) |
Conveyor ceev | 0-1500mm/min |
zog | Peb-theem tsib-xaim AC: 380V 50Hz |
Pib lub zog | 20 kwv |
Lub zog ua haujlwm | 5 kWm |
Lub sijhawm cua sov | 1 Nyob ib ncig ntawm 15 mins |
Kev tswj qhov kub thiab txias | Chav ntsuas kub -350 degree |
Kev tswj qhov kub thiab txias | PID tswj ntxiv rau SSR tsav |
Kev tswj qhov kub thiab txias | ± 1 degree |
Lub tswb txawv txav | Lub tswb ntsuas kub txawv txav |
Tshuab qhov ntev (L * W * H) | 4200×700×1300 |
Tshuab hnyav | 600 KG |
Cov ntaub ntawv tuam txhab
FAQ
Q: Koj puas muaj daim ntawv pov thawj khoom pov thawj?
A: Peb cov khoom muaj CCC, CE, SRIA ntawv pov thawj.
Q: Yuav ua li cas txog qhov kev pab cuam tom qab muag? Yuav ua li cas txog lub warranty?
A: Peb muaj ib pab kws tshaj lij engineers los daws koj cov teeb meem. Txhua qhov chaw uas yuav tsum tau kho thiab hloov pauv yog pub dawb thaum lub sijhawm lav. Peb tseem tuaj yeem muab kev cob qhia rau koj thiab kev teeb tsa ntawm qhov chaw, thiab txhawb kev tswj chaw taws teeb ntawm lub tshuab, lub tshuab siv Suav thiab Askiv interface, yooj yim heev rau kev khiav lag luam.
Q: Koj puas yog lub tuam txhab lag luam lossis chaw tsim khoom?
Peb yog cov chaw tsim khoom tshwj xeeb hauv Cov Tshuab Luam Ntawv, SMT Tshuab, Xaiv thiab Muab Tshuab, Reflow Cub, SMT Cov Kab Ntau Lawm thiab lwm yam khoom SMT.
