PCB Processing Pick And Place Machine

Lub vijtsam LCD nws tus kheej tsis tawm lub teeb, thiab xav tau lub teeb rov qab. LED backlight LCD TV siv LED ua lub teeb nraub qaum, uas muaj tsib qhov zoo tshaj qhov txias cathode fluorescent tube backlight

Xa kev nug

Muaj nuj nqi

PCB txheej txheem xaiv thiab tso tshuab

TV backlight vaj huam sib luag

1. Ultra wide xim gamut, tuaj yeem ncav cuag 105 feem pua txog xim gamut, yog li cov xim ci dua

2. Ultra nyias zoo li, mus txog 1.99 cm, ntau fashionable

3. Kev txuag hluav taws xob thiab kev tiv thaiv ib puag ncig, kev siv hluav taws xob yog 52 feem pua qis dua li ntawm lub teeb txias cathode, thiab tsis muaj cov twj tso kua mis muaj kuab paug ntawm lub raj cathode txias.

Parameter

Qauv	HT-E8S -1200
Dimension
Ntev	25 50 mm
Dav	1650 hli
Qhov siab	1550 hli
Qhov hnyav tag nrho	1700 kg ib
PCB
PCB Ntev Dav	Max: 1200 * 500mm Min: 100 * 100mm
PCB Thickness	0 5-5mm
PCB Clamping	Adjustable siab pneumatic
Mounting hom	Pab pawg xaiv thiab cais qhov chaw \ cais xaiv thiab cais qhov chaw
O.S.
Qhov system	Windows 7
Software	R & D ywj siab
Zaub	Kov npo saib
Ntaus Ntaus	Keyboard, Mus
Vision System
No. Lub Koob Yees Duab	2 teeb lub koob yees duab imported
Lub zeem muag rau kev txheeb xyuas lub davhlau, MARK kho
Mounting Precision	± 0.04mm
Mounting Qhov siab	<15mm (automatic>
Mounting Ceev	45 000 CPH
Cheebtsam	LED, capacitors, resistors, IC, zoo li tus Cheebtsam, thiab lwm yam.
Cheebtsam Chaw	0.2 hli
No. of Feeders Station	28 Pcs
No. ntawm nozzles	12 Pcs
Hwj chim	380AC 50HZ
Kev siv fais fab	4 KW
Kev ua haujlwm ib puag ncig	23 degree ± 3 degree
Conveyor kis tau tus mob	Max ntev: 1200 mm
Kis ceev	≥1000mm / sec
Kev taw qhia kis	Ob txoj kev (xaiv)
Hom kis tau tus mob	Auto online tsav
Huab cua	0 4-0.6mpa (4-6kgf/cm2)150N/min
Hluav taws xob tswj	Kev tshawb fawb ywj pheej thiab kev tsim kho los ntawm ETON
X, Y, Z Axis Tsav txoj kev	High-end magnetic linear motor ntxiv rau Servo lub cev muaj zog
Txoj kev pub mis	Electric feeder nrog ob lub cev muaj zog

E8S-1200 01

SMT txheej txheem ntws ntawm LED lens

Rau cov khoom uas yuav tsum tau txuas rau lub lens, feem ntau yuav tsum tau mount lub LED ua ntej lub lens, thiab ob hom mounting yog ob cais mounting kab. Vim tias qhov kub thiab txias ntawm lub teeb hlaws thiab lub lens sib txawv, lub teeb hlaws yuav tsum tau welded hauv boiler ua ntej lub lens txuas.

FAQ

Q: Kev cob qhia zoo li cas?

A: Tom qab kev yuav peb cov khoom, koj tuaj yeem xa koj cov engineers los kawm hauv peb lub Hoobkas, lossis peb tuaj yeem xa peb cov engineers mus rau koj lub Hoobkas los cob qhia koj cov neeg ua haujlwm rau koj.

Q: Koj hnub xa khoom yog dab tsi?

Hnub xa khoom yog li 20 hnub tom qab them tag nrho.

Q: Kuv xav paub seb koj lub tshuab thauj khoom li cas

Q: Kuv xav paub seb koj lub tshuab thauj khoom li cas?

A: Peb xa khoom mus rau thoob ntiaj teb los ntawm Tuam Tshoj mainland siv huab cua xa los ntawm EMS, UPS, DHL lossis TNT lossis raws li koj qhov kev thov rau qhov chaw. --- Hiav txwv shipping rau tshuab.
